Product Overview
7532 Dynestic 10.5 Classic
Size: 5' x 10' Classic Style
Highlights:
- 15 kW (20 Hp) Air Cooled Spindle
- 14 Position Linear Tool Changer
- 19 Position Drill Block (13 Vertical + 6 Horizontal)
- Start up tooling kit
- 3 machining field, 1 rear and 2 front positions
- 8 Zone multiple vacuum system
- Electronic sensors for pin stops and fence
- X axis position fence
- Pneumatic blast gates for drill and router
- 2 Separate Z axis drives for router and drill head
- Electronic tool measurement
- Light Beam for Safety Barrier
- Automatic centralized lubrication
-Single Becker 590 m^3/h pump
- Air-Conditioned Electrical Cabinet
- Vector Speed: 128 m/min
-Multi-tap Transformer Included; input 208V-240V or 480V-
Technical Data:
- Main Power Supply to Transformer : 208-240V or 480V
- Quick-Connect Breaker Size : 40 amp
- From Transformer to Cabinet Control : 52 amp (with neutral)
- 2nd Power Supply to Vacuum Pump : 208-240V or 480V
- Quick-Connect Breaker Size : 50 amp
- Mains Frequency : 50/60 Hz
- Compressed Air Operating Pressure : 6,0 bar
- Compressed Air Pressure Limit : 8,0 bar
- Extraction Capacity (approx) : 2100 CFM (3400 m3/h)
- Compressed Air Connection : 3/8” (87psi, 10cfm)
- Weight (approx.) : 8800 lbs
