Product Description
CANTEK | PCS14 14″ PNEUMATIC CHOP SAW
Speed up your crosscutting operations.
The Cantek PCS14 14″ pneumatic chop saw is the ideal solution for increasing production on crosscut operations while maintaining optimum safety. Its powerful 5HP motor and adjustable cutting stroke ensure it can effortlessly cut through a wide range of materials and dimensions. A number of features are included to ensure safe operation, such as the infeed/outfeed safety guard, microswitches on all access doors, and security bolt on the saw access door. Available in either left-hand or right-hand operation, depending on your ideal production flow.
Why Cantek PCS14 14″ Pneumatic Chop Saw?
· Large cutting capacity of 1" x10", 2" x9" up to 3" x8".
· Adjustable cutting stroke to ensure optimum cutting speed and cut quality.
· Reliable performance day in and day out.
· Added safety features.
Key Advantages
· Available in Right-Hand and Left-Hand configuration.
· Cut off capacity (thickness x width): 1" x10", 2" x9" up to 3" x8".
· Powerful 5HP main motor.
· Pneumatic foot pedal operation with adjustable cutting speed from the front of the machine (Optional dual push bottom control).
· Fast cutting cycle with up to 95 strokes per minute.
· Cast iron table surface is precision ground assuring high cutting accuracy.
· The material clamp is easily adjusted for workpiece thickness variation.
· CSA/UL magnetic switch.
Safety Features
· Safety guard covers infeed and outfeed to maximize operators' safety during cutting operations.
· Infeed guard has adjustable fingers to minimize opening.
· Door safety limit switches with an extended security bolt.
· Emergency stop button.
Cantek PCS14 14″ Pneumatic Chop Saw | Specifications
DESCRIPTION SPECIFICATION
Cutting capacity (thickness x width) 1″ x 10″, 2″ x 9″, 3″ x 8″
Cycle speed 95 strokes/min
Cycle operation Air
Saw blade size 14″
Saw arbor diameter 1″
Saw blade speed 4100 RPM
Dust exhaust diameter Ø4″ + 400 CFM
Air 16.9 CFM / 70-85 PSI
Motor 5 HP
Table size 24.8” x 23.2”
Net weight 530 lbs.
Shipping weight 642 lbs.
Machine dimensions (LxWxH) 36” x 25” x 48”
Packing dimensions (LxWxH) 30” x 30” x 51.2”
Power requirements 230/1/60 = 23 amps | 230/3/60 = 15.2 amps
460/3/60 = 7.6 amps | 575/3/60 = 6.1 amps
