• CANTEK | PCS18 18″ PNEUMATIC CHOP SAW
  • Cantek PCS18 18″ Pneumatic Chop Saw | Cutting Capacity
  • Blade Access Door Provides full access to the saw blade for convenient blade changes. The door is equipped with a microswitch so that the machine will not operate when the door is open.
  • Optional 10 Degree Tilt Base for Saw Set of 2 tilt base brackets to tilt the saw backwards 10o. Part Number: CANPCS18-TIL
  • Optional 10 Degree Conveyor Tilt Base Set of 4 legs to tilt the infeed and outfeed conveyors backwards by 10o. Part Number: CANPCS18-TILTLEG
  • Optional Flip Stop Adjustable flip stop for outfeed. Part Number: CANPCS-FLIPSTOP
  • CANTEK | PCS18 18″ PNEUMATIC CHOP SAW
  • Optional Gang Stop Adjustable gang stop for outfeed. Part Number: CANPCS-FIXSTO
  • Optional Infeed & Outfeed Conveyor Set Roller Conveyor Infeed 3 meter & Outfeed 3 meter, with (2) legs for each table. Outfeed comes w/ (1) fixed stop & (2) flip stops, with scale, 300mm (12”) wide rollers, and 50mm tall infeed back fence. Part Number: CANPCS-18.24-CONVEYO
  • Pneumatic Actuated Foot Pedal Equipped with an electro-pneumatic foot pedal for convenient operation.
  • Saw Controls The controls are located on top of the table, so the operator has convenient access to turn the machine on or off. The pneumatics can also be turned off to eliminate the stroke where necessary.
  • Optional Dual Push Button Control Dual push-button control is available in lieu of the foot pedal. The saw will only cycle when both push-buttons are pressed simultaneously. *When purchased with machine. Purchased separately for customer install: Part Number: CANPCS18-DUALPAL **Dual push button control is required for the state of California
  • Safety Guard A safety guard is included with each saw covering both infeed and outfeed to keep operators hands away from the blade during operation. The adjustable fingers on the infeed are designed to minimize the opening to keep hands away from the cutting blade. Clear plastic covers allow the operator to view towards the cutting line to ensure no impediments are near.

    • CANTEK | PCS18 18″ PNEUMATIC CHOP SAW

    CANTEK

    $8,100.00
    Request A Quote
    (No reviews yet) Write a Review
    SKU:
    CANTEK | PCS18 18″ PNEUMATIC CHOP SAW

    Product Description

    CANTEK | PCS18 18″ PNEUMATIC CHOP SAW

    Speed up your crosscutting operations.

    The Cantek PCS18 18″ pneumatic chop saw is the ideal solution for increasing production on crosscut operations while maintaining optimum safety. Its powerful 10HP motor and adjustable cutting stroke ensure it can effortlessly cut through a wide range of materials and dimensions. A number of features are included to ensure safe operation, such as the infeed/outfeed safety guard, microswitches on all access doors, and security bolt on the saw access door. Available in either left-hand or right-hand operation, depending on your ideal production flow.



    Why Cantek PCS18 18″ Pneumatic Chop Saw?

    · Large cutting capacity of 2" x12" up to 4" x10".

    · Adjustable cutting stroke to ensure optimum cutting speed and cut quality.

    · Reliable performance day in and day out.

    · Added safety features.



    Key Advantages

    · Available in Right Hand & Left-Hand configuration.

    · Cut off capacity (thickness x width): 2″ x 12″, 3″ x 11″, 4″ x 10″.

    · Powerful 10HP main motor.

    · Pneumatic foot pedal operation with adjustable cutting speed from the front of the machine (Optional dual push bottom control).

    · Fast cutting cycle with up to 45 strokes per minute.

    · Cast iron table surface is precision ground assuring high cutting accuracy.

    · The material clamp is easily adjusted for workpiece thickness variation.

    · CSA/UL magnetic switch.



    Safety Features

    · Safety guard covers infeed and outfeed to maximize operators' safety during cutting operations.

    · Infeed guard has adjustable fingers to minimize opening.

    · Door safety limit switches with an extended security bolt.

    · Emergency stop button.



    Cantek PCS18 18″ Pneumatic Chop Saw | Specifications



    DESCRIPTION                                                  SPECIFICATION

    Cutting capacity (thickness x width)       2″ x 12″, 3″ x 11″, 4″ x 10″

    Cycle speed                                                      45 strokes/min

    Cycle operation                                                        Air

    Saw blade size                                                          1 8″

    Saw arbor diameter                                                  1″

    Saw blade speed                                                   3600 RPM

    Dust exhaust diameter                                    Ø4″ = 400 CFM

    Air                                                                 9.8 CFM / 70-85 PSI

    Motor                                                                      10 HP

    Table size                                                           26" x 27 ½"

    Net weight                                                               770 lbs.

    Shipping weight                                                     902 lbs.

    Machine dimensions (LxWxH)                          42” x 27” x 48”

    Packing dimensions (L x W x H)                   37” x 33 ½” x 53.2”

    Power requirements           230/3/60 = 28 amps | 460/3/60 = 14 amps | 575/3/60 = 11 amps
