Delta Series 1/2" CED x 1-1/8" LOC x 1/2" Shank x 2 Flt. Downshear Finishing

(No reviews yet) Write a Review
$76.47
Delta Series 1/2" CED x 1-1/8" LOC x 1/2" Shank x 2 Flt. Downshear Finishing
SKU:
D500.1125.21
Adding to cart… The item has been added

Product Overview

Delta Series Solid Carbide 2 Flute Downshear Finishing Tool
Materials: Raw and laminated wood composite and solid wood materials
Application: The D500.1125.21 features a robust 1/2" diameter x 1" (2.6xD) length of cut x 1/2" shank 2 flute 30° high helix downshear design.  This design ensures a smooth top edge finish and is primarily used for slot and pocket routing operations including dado, grooving, rabbiting, and corner clean out applications.  The D500.1125.21 can also be used for part cut out and profile routing operations when downshear cutting pressure is needed to reduce or eliminate part movement.  Part cut out and profile routing operations will likely chip or blowout the bottom edge of most materials, but this can be minimized when routing on a spoil board.  Downshear tools should never be used for plunging cutting operations as this can result in a fire.
  • Delta Series tools are designed and manufactured in the USA using premium solid carbide materials, a precision grinding process and exclusive edge finish.
  • Options include chip breakers, neck clearance and performance tool coatings.
  • High tolerance shank for use with high accuracy tool holding systems.

MILL DIAMETER:1/2"

SHANK DIAMETER:1/2"

LENGTH OF CUT:1-1/8"

OVERALL LENGTH:3"

FLUTES:2FLUTE

STYLE:Downshear

MATERIAL:Solid Carbide
