Product Description
NT-iGlue450
• Automatic dovetail glue application machine
• No setup required between diff erent dovetail designs
• No setup required between part sizes
• No mess due to inconsistent glue application
• Simply place the parts against the fence and the iGlue will scan,
apply glue to either male or female side of the joint
automatically, all with in seconds
• Working width: 25.4 - 450mm (1" - 18")
• Working thickness: 6 - 50mm (1/4" - 2")
• Working length minimum: 100mm (4")
• (3) Programmable quick change working speeds
• Maximum operating speed: 1.4in/s
• Siko counter fence for 0-2" depth setting
• Replaceable no drip glue nozzle
• Glue pot and water pot on an internal cart system that pulls
outside the machine for easy access
• LED illuminated working area changes color based on work mode
• Automatic sleep mode will place the nozzle into a water bath after
a few minutes without use to keep glue tip fresh
• Auto cleaning mode fl ushes glue out of system easily
• Single pneumatic connection with FLR included
• Easy smartphone integration for detailed parameter adjustments and maintenance
• (1) gallon of Master Grip Glue included
• Glue reservoir: 10L Adjustable pressure glue pot included
• Water reservoir: 4L Adjustable pressure water pot included
• Recommended glue type: Water soluble PVA glue 8,000mpa s @ 60-80°
• iGlue fence extension included
• Machine / Shipping weight: 300lbs / 412lbs
• Machine / Shipping dimensions (LxWxH): 38" x 20" x 44" / 42" x 21" x 49"
• 208V/230V/460V 3PH 60HZ; 200W; 1Amp or 220V 1PH 60HZ; 2 Amp
• Tool box and manual included
• Standard Northtech one year parts warranty
• Northtech off ers a full line of dust collectors and fl exible dust hose for any application.
• All machines are tested at our corporate headquarters in Indiana prior to shipment providing trouble
